Главная страница /Продукция/Антидроны/Counter UAV System with 3km Detection Range RF Neutralization and 360 Degree Monitoring for Comprehensive Drone Defense

Counter UAV System with 3km Detection Range RF Neutralization and 360 Degree Monitoring for Comprehensive Drone Defense

1
MOQ
Please consult a sales engineer
цена
Counter UAV System with 3km Detection Range RF Neutralization and 360 Degree Monitoring for Comprehensive Drone Defense
Характеристики Галерея Характер продукции Спросите цитату
Характеристики
Характеристики
Производственная мощность: 10000 штук/год
Источник: Китай
Спецификация: тюремный глушитель
Диапазон обнаружения: 1-3 км.
Транспортный пакет: Пакет из алюминиевого сплава
На открытом воздухе использование: Система защиты от БПЛА/противодействующий дрон/подавитель дронов
Выделить:

3km Detection Range Counter UAV System

,

RF Neutralization Counter-UAS Solution

,

360 Degree Monitoring Anti-drone System
Основная информация
Место происхождения: Китай
Фирменное наименование: UND
Оплата и доставка Условия
Время доставки: 5-8 дней
Условия оплаты: Т/Т
Поставка способности: 100
Характер продукции
Counter UAV / Counter-UAS Solutions for Drone Detection and Countermeasure
Auto Counter UAVs Solution
As the rapid evolution of low-cost, highly capable drones presents new security challenges, the demand for counter-drone technology continues to grow. Our integrated anti-drone solution offers a unique and flexible approach to comprehensive drone defense protection.
The system provides RF sensor passive detection, radar active surveillance detection, EO/IR tracking and location of multiple detected low-flying drones, along with mitigation capabilities through the RF neutralization system.
Counter UAV System with 3km Detection Range RF Neutralization and 360 Degree Monitoring for Comprehensive Drone Defense 0
Working Principle
Counter UAV System with 3km Detection Range RF Neutralization and 360 Degree Monitoring for Comprehensive Drone Defense 1
Radar Detection Subsystem
Radar systems emit electromagnetic waves and process the echoes reflected by objects to locate them. Our drone detection radar provides front-end real-time detection and monitoring with 360°/90° coverage and fast scan rates, capable of detecting drones at distances up to 1-3km with automatic detection and tracking of multiple targets.
Radar Surveillance Systems Features:
  • Microwave Pulse Doppler technology based (C-band & S-band)
  • Detection of wide variety of moving objects including pedestrians, land vehicles, and low-flying drones
  • 360°/90° real-time monitoring coverage
  • Available for short range, medium range, and long range requirements
Drone detection radar works in combination with RF detection systems or RF neutralization systems to provide comprehensive drone detection and counteraction for drone intrusions within protected areas.
RF Detection Subsystem
Civil drones are typically operated via radio control signals and often have on-board data link transmitters for real-time sensor download. Our RF detection system can passively detect and identify RF transmissions related to drones, even in low-power or RF-noisy conditions.
RF Drone Detection Capabilities:
  • RF sensor detection for any drone emitting RF signals (known and unidentified drones)
  • 360° detection radius up to 3 kilometer diameter
  • Simultaneous detection of multiple drones during intrusion events
  • Geolocation capability for both drone and drone controller
RF sensor detection systems work together with radar detection systems to provide 3D location data, flight height, and air speed measurements. Once a drone is detected, the system automatically triggers an alert.
EO/IR Camera Tracking Subsystem
Our visual and thermal camera surveillance guarantees the ability to view any target, day or night. This subsystem serves as an additional layer on top of RF/Radar systems to provide visual imaging of detected targets.
Camera Tracking Features:
  • High sensitivity tracking capability within detection range
  • Excellent visual output for day camera and thermal imaging camera
  • Visual intrusion alarm capabilities
RF Neutralization Subsystem
The RF neutralization subsystem is designed to neutralize unauthorized drone flights by interfering with their control and navigation signals.
Signal Type Frequency Range Effective Range
GNSS 1550-1620 MHz 3-5km
Remote Control Signal 860-930MHz; 2400-2500MHz; 5725-5850MHz 1-3km
Optional Frequencies 5150-5350MHz; 315MHz; 433MHz -
Both omnidirectional and directional antennas are available, with additional frequency bands available upon demand.
Monitoring Software Center
The information processing and command center of the automatic UAV detection and defense system controls each subsystem and equipment through collection, presentation, analysis, statistics, and query of various information, along with real-time system control.
Software Center Features:
  • Simple, intuitive display and control of one or more subsystems
  • Microsoft Windows based platform
  • User definable alert and exclusion zones
  • Automatic selection of background maps
  • Continuous record and playback facility for post-event analysis
