70m Long Range Cell Phone GPS Jammer with 16 Antennas and 5 Cooling Fans for Enhanced Signal Blocking

1
MOQ
Please consult a sales engineer
Cena £
70m Long Range Cell Phone GPS Jammer with 16 Antennas and 5 Cooling Fans for Enhanced Signal Blocking
cechy Galeria opis produktu Poprosić o wycenę
cechy
specyfikacje
Zasilanie: Zasilacz sieciowy (AC220V-DC12V)
Promień ekranujący: 5-50 metrów (w zależności od siły sygnału)
Wymiary: 238×60×395 mm
Waga netto: 7,0 kg
Opcjonalne częstotliwości: 4G2300, WIFI5.8G, 3.6G, UHF200-400MHz, kamera bezprzewodowa 1000-1390MHz itp.
Kolor: Czarny
Podkreślić:

70m Long Range Cell Phone GPS Jammer

,

16 Antennas Signal Blocker

,

5 Cooling Fans RF Jammer

Podstawowe informacje
Miejsce pochodzenia: Chiny
Nazwa handlowa: UND
Numer modelu: U-016B
Zapłata
Czas dostawy: 5-8 dni
Zasady płatności: T/T
Możliwość Supply: 100
opis produktu
Cell Phone GPS Jammer - 16 Antennas with 5 Cooling Fans - 70m Long Range
Product Overview

This advanced signal blocking device provides comprehensive jamming capabilities for cellular networks (2G, 3G, 4G), GPS, WiFi, and LOJACK signals. Each frequency band can be independently controlled without affecting other band operations.

The device features an effective jamming radius of 5-40 meters, depending on local signal strength and environmental conditions. With an integrated cooling system including heat sinks and multiple fans, it supports continuous 24/7 operation.

Flexible power options include standard AC adapter operation, battery charging compatibility, and direct vehicle use via car cigarette lighter adapter.

Key Features
  • Total output power: 38W
  • Continuous 24-hour operation capability
  • Stable performance with cost-effective design
  • Advanced cooling system with multiple fans for optimal thermal management
  • Individual band power adjustment for precise control
  • Vehicle compatibility with car adapter support
  • Sixteen frequency channels covering multiple standards including Walkie Talkie, GPS, Galileo, Compass, Glonass, UMTS, WiFi, AWS, and LTE 4G
Technical Specifications
Output Port Frequency Average Output Power Channel Output Power
CDMA851-894MHz35dBm5dBm/30KHz(min)
GSM925-960MHz35dBm5dBm/30KHz(min)
DCS1805-1880MHz33dBm2dBm/30KHz(min)
PCS1920-1990MHz33dBm2dBm/30KHz(min)
3G2110-2170MHz33dBm2dBm/30KHz(min)
WIFI2.4G2400-2500MHz30dBm0dBm/30KHz(min)
GPS1575MHz32dBm5dBm/30KHz(min)
4G LTE700/LTE800725-825MHz34dBm3dBm/30KHz(min)
4G WIMAX2500-2690MHz30dBm0dBm/30KHz(min)
UHF400-470MHz34dBm2dBm/30KHz(min)
VHF135-174MHz34dBm2dBm/30KHz(min)
LOJACK173.075MHz34dBm5dBm/30KHz(min)
315315MHz33dBm5dBm/30KHz(min)
433433MHz34dBm5dBm/30KHz(min)
868868MHz35dBm5dBm/30KHz(min)
GPSL2-L51170-1280MHz32dBm5dBm/30KHz(min)
Additional Specifications
  • Optional frequencies: 4G2300, WIFI5.8G, 3.6G, UHF200-400MHz, Wireless camera 1000-1390MHz, etc.
  • Power supply: AC adapter (AC220V-DC12V)
  • Shielding radius: 5-50 meters (depending on signal strength)
  • Dimensions: 238*60*395mm
  • Net weight: 7.0kg
Application Areas
  • Meeting rooms, conference rooms, museums, galleries, theaters, concert halls
  • Churches, temples, restaurants, classrooms, training centers
  • Factories, banks, trains, buses, and public transportation
Important Note: For sensitive locations such as hospitals and gas stations, please conduct field testing first to ensure no interference occurs with critical equipment.
Package Contents
  • Jammer Kit *1
  • Omni Antenna *16
  • Car Charger *1
  • Power Adapter *1
