| Parameter | Uplink | Downlink |
|---|---|---|
| GSM 900 | 890-915 MHz | 935-960 MHz |
| DCS 1800 | 1710-1785 MHz | 1805-1880 MHz |
| Gain | 70dB±2dB | 75dB±2dB |
| Output Power | 20dBm±2dBm | 23dBm±2dBm |
| Band Width | Wide Band |
| Manual Gain Control | 31dB / 1dB Step |
| ALC | ≥ 20dB |
| Ripple in Band | 8dB |
| Noise Figure | ≤ 6dB |
| VSWR | ≤ 2.0 |
| Intermodulation Products | ≤ -40dBc |
| Spurious Emission | 9KHz~1GHz: ≤ -36dBm/30KHz 1~12.75GHz: ≤ -30dBm/30KHz |
| Time Delay | ≤ 1.5 μs |
| Frequency Stability | ≤ 0.01ppm |
| MTBF | > 50,000 hours |
| Impedance | 50Ω |
| Power Supply | AC 90-264V, DC 10V/10A |
| Power LED | Power indicator |
| Alarm LED | Red: Self oscillation or Strong input signal Green: Normal operation |
| RF Connector | N-Female |
| Switch | Power Switch |
| Cooling System | Heatsink convection cooling |
| Humidity | < 90% |
| Operating Temperature | -10°C to +55°C |
| Environment Conditions | IP40 (Indoor use) |
| Installation Type | Wall mounting |
| Dimensions | 189 * 268 * 58mm |
| Weight | 4.5kg |
