3km Detection Range Anti-drone System with RF Neutralization and 360 Degree Monitoring Counter UAV Solution

1
MOQ
Please consult a sales engineer
가격
3km Detection Range Anti-drone System with RF Neutralization and 360 Degree Monitoring Counter UAV Solution
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
감지 범위: 1km/3km/4-6km
주요 하이라이트: 전파 교란기
애플리케이션: 보안 장비
기능: 드론 방해기
등록 상표: 유효한 OEM
생산능력: 10000 조각/년
강조하다:

3km detection range anti-drone system

,

RF neutralization counter UAV solution

,

360 degree monitoring drone defense system
기본 정보
원래 장소: 중국
브랜드 이름: UND
결제 및 배송 조건
배달 시간: 5~8일
지불 조건: 티/티
공급 능력: 100
제품 설명
Killing Microwave Radar and RF Jammer - Air Force Deploys Drone Anti-drone Systems
Our integrated anti-drone solution provides comprehensive drone defense protection through a unique and flexible approach to counter evolving drone threats.
Auto Counter UAVs Solution
As low-cost, highly capable drones present new security challenges, our counter-drone technology offers comprehensive protection through RF sensor passive detection, radar active surveillance, EO/IR tracking, and RF neutralization systems.
Radar Detection Subsystem
Drone detection radar provides real-time detection and monitoring with 360°/90° coverage and fast scan rates, capable of detecting drones at distances up to 1-3km with automatic detection and tracking of multiple targets.
  • Microwave Pulse Doppler technology (C-band & S-band)
  • Detection of various moving objects including pedestrians, vehicles, and low-flying drones
  • 360°/90° real-time monitoring capabilities
  • Available for short, medium, and long-range requirements
Works in combination with RF detection or neutralization systems to provide comprehensive drone detection and countermeasures.
RF Detection Subsystem
Passively detects and identifies RF transmissions related to drones, even in low-power or noisy RF conditions, providing detection of both known and unidentified drones.
  • 360° detection radius up to 3km diameter
  • Simultaneous detection of multiple drones during intrusion
  • Geolocation of both drone and drone controller
Integrates with radar detection to provide 3D location, flight height, and air speed data, triggering alerts upon drone detection.
EO Visual and Thermal Camera Tracking
Provides additional surveillance layer with day/night viewing capability through high-sensitivity tracking and excellent visual output.
  • High sensitivity tracking within detection range
  • Excellent day camera and thermal imaging capabilities
  • Visual intrusion alarm system
RF Neutralization Subsystem
Designed to neutralize unauthorized drone flights by interfering with control and navigation signals.
  • GNSS: 1550-1620 MHz
  • Remote Control Signal: 860-930MHz; 2400-2500MHz; 5725-5850MHz
  • Optional Frequencies: 5150-5350MHz; 315MHz; 433MHz
  • Omnidirectional and directional antenna options
  • Custom jamming bands available upon demand
  • Range: Remote Control Signal 1-3km; GNSS Signal 3-5km
Monitoring Software Center
Information processing and command center for automatic UAV detection and defense system, controlling all subsystems through comprehensive data management.
  • Simple, intuitive display and control of multiple subsystems
  • Microsoft Windows based platform
  • User-definable alert and exclusion zones
  • Automatic background map selection
  • Continuous recording and playback for post-event analysis
3km Detection Range Anti-drone System with RF Neutralization and 360 Degree Monitoring Counter UAV Solution 0
