80W 2G 3G 4G Mobile Phone Signal Jammer with 8 Antennas for Prison Security
This high-performance signal jammer features 80W output power and 8 separate frequency bands with individual power control. Designed specifically for prison security applications, it effectively blocks communications between mobile devices and cellular networks.
Product Overview
The signal jammer is engineered to disrupt communications between RF wireless equipment including mobile phones and cellular base stations, VHF/UHF walkie-talkies, GPS, Wi-Fi 11 a/b/g/n, satellite phones, radio phones, and remote controls without interfering with other communications systems.
Our jammers are designed to cut off down-link only, ensuring no interference with base stations and repeaters. The system has been tested in numerous projects worldwide, guaranteeing reliable operation and stability.
Applications
Ideal for meetings, conferences, seminars, libraries, cinemas, executive offices, board meetings, religious places, public transport, concert halls, restaurants, educational institutions, and particularly prisons where communication control is critical.
Key Features
- 8 separate switches for individual band power adjustment
- Simultaneous blocking of 8 different frequency bands
- Effective jamming range of 30-100 meters depending on local signal density
- Eight omni-directional antennas for optimal coverage
- Ultra high frequency broadband jamming technology
- Advanced cooling system for continuous operation
- Waterproof aviation connectors and professional waterproof casing for outdoor use
- Customizable frequency ranges for various cellular standards worldwide
Supported Frequency Bands
LoJack 173MHz, VHF, UHF, Walkie-talkie, interphone, 433MHz, 315MHz, 868MHz, 450MHz, iDEN, CDMA, GSM, GPRS, DCS, PCS, AWS, WCDMA, UMTS, 3G, 4G, LTE 700, LTE 800, LTE 2300, LTE 2600, GPS L1, GPS L2, Galileo, Compass, Glonass, WIFI, Bluetooth, Spy camera, WIMAX, UAV, Drone, 5.8G, and more.
Technical Specifications
| Output Port |
Frequency |
Average Output Power |
| GSM |
925-960MHz |
40dBm |
| DCS |
1805-1880MHz |
40dBm |
| GPS L1 |
1570-1580MHz |
40dBm |
| WiFi |
2400-2500MHz |
39dBm |
| 3G |
2110-2170MHz |
40dBm |
| LTE800 |
791-821MHz |
40dBm |
| LTE2600 |
2620-2690MHz |
39dBm |
| Lojack |
173MHz |
40dBm |
General Specifications
Power Supply: AC110-240V, DC28V
Energy Consumption: 240W
Dimensions: 380(L) * 300(W) * 90(H) mm
Weight: 7kg
Operating Temperature: -25°C to +55°C
Output Power: 80W
Jamming Range: 10-80 meters radius (depending on local signal intensity)
Humidity: 5% - 95%
Antennas: 8 external directional panel antennas
Note: Jamming range varies depending on local signal strength and environmental conditions.
