Home /Products/Ground Surveillance Radar/C Band (5.5-5.8GHz) Ground Surveillance Radar with 360° Surveillance and All-Weather Adaptability for Border Security

C Band (5.5-5.8GHz) Ground Surveillance Radar with 360° Surveillance and All-Weather Adaptability for Border Security

1
MOQ
Please consult a sales engineer
Price
C Band (5.5-5.8GHz) Ground Surveillance Radar with 360° Surveillance and All-Weather Adaptability for Border Security
Features Gallery Product Description Chat Now
Features
Specifications
Working Frequency: C Band (5.5-5.8GHz)
Detection Range: 2.5km (Pedestrians) 5km (Vehicles)
Elevation Coverage: 9°
Target Detection Speed: 0.2m/s - 30m/s
Net Weight: ≤50kg
Power Supply: AC220V/160W
Highlight:

C Band Ground Surveillance Radar

,

360° Surveillance Phased Array Radar

,

All-Weather Adaptability Security Surveillance Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U 215-4C
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
C Band Detection Ground Surveillance Radar for Border Warning Application
Ground Surveillance Radar U 215-4C / C Band

The U 215-4C is an advanced security surveillance radar system featuring phased array technology with stable performance, designed for 360° detection of ground moving targets. This system integrates four U 215-1C radars working in unison, providing comprehensive surveillance coverage.

Key Features
  • High data rate and superior positioning accuracy
  • Multi-Input Multi-Output (MIMO) system architecture
  • All-weather operational capability
Applications
Border security, oil field protection, prison surveillance, and other critical area security applications
Technical Specifications
Parameter Specification
Working Mode Phased array + Pulse Doppler
Working Frequency C band (5.5-5.8GHz)
Detection Range 2.5km (Pedestrians)
5km (Vehicles)
Minimum Detection Range ≤100m
Azimuth Coverage 4-panel: 360°
Elevation Coverage 9°
Distance Accuracy ≤5m
Azimuth Accuracy ≤1.0°
Target Detection Speed 0.2m/s - 30m/s
Speed Precision ≤0.2m/s
Data Rate ≤1.5s
Net Weight ≤50kg
Power Supply AC220V/160W
Interface Ethernet (UDP protocol)
Dimensions 580mm x 580mm x 820mm
Working Temperature -40°C to +60°C
Environmental Protection Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof
C Band (5.5-5.8GHz) Ground Surveillance Radar with 360° Surveillance and All-Weather Adaptability for Border Security 0
Tag:

Ground Radar System

Ground Security Radar

Compact Surveillance Radar
