360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability

1
MOQ
Please consult a sales engineer
Price
360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability
Features Gallery Product Description Chat Now
Features
Specifications
Net Weight: ≤50kg
Power Supply: AC220V/160W
Target Detection Speed: 0.2m/s - 30m/s
Azimuth Coverage: 360° (4-panel Configuration)
Detection Range: 2.5km (Pedestrians) 5km (Vehicles)
Working Frequency: C Band (5.5-5.8GHz)
Highlight:

360° Surveillance Ground Surveillance Radar

,

5km Vehicle Detection Security Surveillance Radar

,

All-Weather Adaptability Phased Array Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U 215-4C
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
360 Degree Coverage Intrusion Detection Ground Surveillance Radar Sensor
Ground Surveillance Radar U 215-4C / C Band
The U 215-4C is an advanced security surveillance radar system featuring phased array technology with stable performance, designed specifically for 360° detection of ground moving targets. This system integrates four U 215-1C radar units working in unison to provide comprehensive surveillance coverage.
Key Features
  • High data rate and superior positioning accuracy
  • Multi-Input Multi-Output (MIMO) system architecture
  • All-weather operational capability
Applications
Ideal for security surveillance in border areas, oil fields, prisons, and other critical infrastructure locations requiring reliable intrusion detection.
Technical Specifications
Parameter Specification
Working Mode Phased Array + Pulse Doppler
Working Frequency C Band (5.5-5.8GHz)
Detection Range 2.5km (Pedestrians)
5km (Vehicles)
Minimum Detection Range ≤100m
Azimuth Coverage 360° (4-panel configuration)
Elevation Coverage 9°
Distance Accuracy ≤5m
Azimuth Accuracy ≤1.0°
Target Detection Speed 0.2m/s - 30m/s
Speed Precision ≤0.2m/s
Data Rate ≤1.5s
Net Weight ≤50kg
Power Supply AC220V/160W
Interface Ethernet (UDP protocol)
Dimensions 580mm * 580mm * 820mm
Working Temperature -40°C to +60°C
Environmental Protection Rain-proof, Dust Prevention, Sand-prevention, Moisture-proof, Mould-proof and Salt-proof
