Home /Products/Ground Surveillance Radar/C Band (5.5-5.8GHz) Ground Surveillance Radar with 1.5km Pedestrian Detection and All-Weather Adaptability for Perimeter Security

C Band (5.5-5.8GHz) Ground Surveillance Radar with 1.5km Pedestrian Detection and All-Weather Adaptability for Perimeter Security

1
MOQ
Please consult a sales engineer
Price
C Band (5.5-5.8GHz) Ground Surveillance Radar with 1.5km Pedestrian Detection and All-Weather Adaptability for Perimeter Security
Features Gallery Product Description Chat Now
Features
Specifications
Net Weight: ≤3.8kg
Power Supply: AC220V/DC12V (External Battery)/35W
Dimension: 324mm X 295mm X 92mm
Working Temperature: -40°C To +60°C
Elevation Coverage: 18°
Working Frequency: C Band (5.5-5.8GHz)
Highlight:

C Band Ground Surveillance Radar

,

1.5km Pedestrian Detection Perimeter Surveillance Radar

,

All-Weather Adaptability Security Surveillance Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U101-1C
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
Perimeter Surveillance Security Ground Surveillance Radar for Water Facilities
Ground Surveillance Radar U101-1C / C Band
The U101-1C provides state-of-the-art protection for airfield and ground security applications. This C-band radar system is specifically designed to detect and track ground targets, providing immediate reporting of target position and coordinate information to facilitate rapid threat response planning.
Key Features
High data rate and superior positioning accuracy
Multi-Input Multi-Output (MIMO) system architecture
All-weather operational capability
Applications
Checkpoints, prisons, reservoirs, perimeter security, oil fields, and similar critical infrastructure protection scenarios.
Technical Specifications
Item Specification
Working mode Phased array + Pulse Doppler
Working frequency C band (5.5-5.8GHz)
Detection range 1.5km (Pedestrians)
3km (Vehicles)
Minimum detection range ≤100m
Azimuth coverage Single panel: 90° (Dual panel: 180°, 3-panel: 270°, 4-panel: 360°)
Elevation coverage 18°
Distance accuracy ≤10m
Azimuth Accuracy ≤1.0°
Target detection speed 0.2m/s - 30m/s
Speed precision ≤0.2m/s
Data rate ≤1.5s
Net weight ≤3.8kg
Power supply AC220V/DC12V (External Battery)/35W
Interface Ethernet (UDP protocol)
Dimension 324mm x 295mm x 92mm
Working temperature -40°C to +60°C
Working Environment Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof
