8 Band High Power 550W Drone Jammer with 1000-2000m Range Anti-Drone System UAV Countermeasure

1
MOQ
Please consult a sales engineer
Price
8 Band High Power 550W Drone Jammer with 1000-2000m Range Anti-Drone System UAV Countermeasure
Features Gallery Product Description Chat Now
Features
Specifications
Total Power: 550W
Power Supply: AC220V
Interference Range: 1000-2000m
Warranty: 1 Year
Color: Black
Power Source: Battery
Highlight:

8 Band Drone Jammer

,

550W Power Anti-Drone System

,

1000-2000m Range UAV Jammer
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U-V8
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
8 Band High Power Blocker Anti-Drone System
Advanced UAV countermeasure solution for suppression of FPV, GPS, and WiFi signal drone jamming applications.
Background
Unmanned Aerial Vehicles (UAVs), commonly known as drones, are aircraft operated via radio remote control or autonomous programming. In civilian applications, drones serve numerous industrial purposes including aerial photography, agriculture, plant protection, express delivery, disaster rescue, wildlife observation, disease monitoring, surveying, news reporting, power line inspection, and film production.
8 Band High Power 550W Drone Jammer with 1000-2000m Range Anti-Drone System UAV Countermeasure 0
System Purpose
This independently developed and manufactured jammer system is designed to:
  • Disrupt all communication signals between drones and their controllers
  • Render drone remote controls inoperative
  • Prevent drone positioning, forcing landing, hovering, or return protocols
Technical Characteristics
  • Utilizes super-high frequency with high effective power output
  • Features effective channel power with extended interference radius
  • Selectively interferes with mobile system downlink frequencies without disrupting base station operations
  • Incorporates imported circuit elements with slow startup design for stable high-integration operation
Frequency Specifications
Frequency Operating Frequency Port Output Power per Channel
2.4G 2400-2485MHz 2 band 50 dBm±1
5.8G 5720-5850MHz 2 band 47 dBm±1
1.5G 1565-1585MHz 1 band 47 dBm±1
1.2G 1170-1280MHz 1 band 47 dBm±1
433MHz 433MHz 1 band 47 dBm±1
900MHz 850-930MHz 1 band 47 dBm±1
Total Power: 550W
Power Supply: AC220V
Interference Range: 1000-2000m (depending on visible network signal conditions)
Installation Guidelines
For optimal performance:
  • Position equipment to cover the center of the target area
  • Ensure no obstacles within direct line of sight of device antennas
Operation Procedure
  1. Connect all antenna cables correctly to the device
  2. Install plate antenna at fixed height, aimed toward jurisdiction area for emission
  3. Connect power cord to AC220V mains supply
  4. Connect device cooling fan
  5. Turn on power switch (verify power indicator light illuminates)
