360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability

1
MOQ
Please consult a sales engineer
Price
360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability
Features Gallery Product Description Chat Now
Features
Specifications
Speed Precision: ≤0.2m/s
Net Weight: ≤50kg
Power Supply: AC220V/160W
Dimensions: 580mm * 580mm * 820mm
Working Temperature: -40°C To +60°C
Azimuth Coverage: 4-panel: 360°
Highlight:

360° Surveillance Ground Surveillance Radar

,

5km Vehicle Detection Security Surveillance Radar

,

All-Weather Adaptability Phased Array Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U 215-4C
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
Security Ground Surveillance Radar Through Video Linking Integrated Visual Intruder Verification
Ground Surveillance Radar U 215-4C / C Band

The U 215-4C is an advanced security surveillance radar system featuring the same phased array technology as the U 215-1C, enhanced with superior performance and reliability for comprehensive 360° ground moving target detection. This system integrates four U 215-1C radar units working in unison to provide expanded coverage and enhanced surveillance capabilities.

Key Features
  • High data rate with exceptional positioning accuracy
  • Multi-Input Multi-Output (MIMO) system architecture
  • All-weather operational capability
Applications

Ideal for perimeter security surveillance in border areas, oil fields, prisons, and other critical infrastructure locations requiring advanced intrusion detection.

Technical Specifications
Parameter Specification
Working Mode Phased Array + Pulse Doppler
Working Frequency C Band (5.5-5.8GHz)
Detection Range 2.5km (Pedestrians)
5km (Vehicles)
Minimum Detection Range ≤100m
Azimuth Coverage 4-panel: 360°
Elevation Coverage 9°
Distance Accuracy ≤5m
Azimuth Accuracy ≤1.0°
Target Detection Speed 0.2m/s - 30m/s
Speed Precision ≤0.2m/s
Data Rate ≤1.5s
Net Weight ≤50kg
Power Supply AC220V/160W
Interface Ethernet (UDP Protocol)
Dimensions 580mm * 580mm * 820mm
Working Temperature -40°C to +60°C
Working Environment Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof
