Home /Products/Ground Surveillance Radar/360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability

360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability

1
MOQ
Please consult a sales engineer
Price
360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability
Features Gallery Product Description Chat Now
Features
Specifications
Azimuth Coverage: 360° (4-panel Configuration)
Target Detection Speed: 0.2m/s - 30m/s
Net Weight: ≤50kg
Dimensions: 580mm × 580mm × 820mm
Operating Temperature: -40°C To +60°C
Minimum Detection Range: ≤100m
Highlight:

360° Surveillance Ground Surveillance Radar

,

5km Vehicle Detection Phased Array Radar

,

All-Weather Adaptability Security Surveillance Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U 215-4C
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
U 215-4C Ground Surveillance Radar System
The U 215-4C is an advanced security surveillance radar system operating in the C-band frequency range. This sophisticated phased array radar delivers comprehensive 360° surveillance coverage for ground moving target detection across various urban environments.
Advanced Radar Technology
Built on the proven U 215-1C platform, the U 215-4C integrates four individual radar arrays working in unison to provide complete circular coverage. This multi-array configuration ensures superior detection capabilities and operational reliability.
Key Features
  • High data rate with exceptional positioning accuracy
  • Multi-Input Multi-Output (MIMO) system architecture
  • All-weather operational capability
  • Comprehensive 360° surveillance coverage
  • Advanced phased array pulse Doppler technology
Application Areas
Ideal for securing critical infrastructure including border perimeters, oil fields, prisons, and other high-security zones requiring reliable ground surveillance.
Technical Specifications
Parameter Specification
Working Mode Phased Array + Pulse Doppler
Working Frequency C Band (5.5-5.8GHz)
Detection Range 2.5km (Pedestrians)
5km (Vehicles)
Minimum Detection Range ≤100m
Azimuth Coverage 360° (4-panel configuration)
Elevation Coverage 9°
Distance Accuracy ≤5m
Azimuth Accuracy ≤1.0°
Target Detection Speed 0.2m/s - 30m/s
Speed Precision ≤0.2m/s
Data Rate ≤1.5s
Net Weight ≤50kg
Power Supply AC220V/160W
Interface Ethernet (UDP protocol)
Dimensions 580mm * 580mm * 820mm
Operating Temperature -40°C to +60°C
Environmental Protection Rain-proof, Dust Prevention, Sand-prevention, Moisture-proof, Mould-proof, Salt-proof
