360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability

1
MOQ
Please consult a sales engineer
Price
360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability
Features Gallery Product Description Chat Now
Features
Specifications
Net Weight: ≤50kg
Dimensions: 580mm × 580mm × 820mm
Working Temperature: -40°C To +60°C
Power Supply: AC220V/160W
Target Detection Speed: 0.2m/s - 30m/s
Azimuth Coverage: 4-panel: 360°
Highlight:

360° Surveillance Ground Surveillance Radar

,

5km Vehicle Detection Security Surveillance Radar

,

All-Weather Adaptability Phased Array Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U 215-4C
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
Pre-Warning & Security Alarming Ground Surveillance Radar with 360° Full Coverage
Ground Surveillance Radar U 215-4C / C Band

The U 215-4C is an advanced security surveillance radar system featuring the same phased array technology as the U 215-1C model, but with enhanced capabilities. This sophisticated radar is engineered for comprehensive 360° surveillance and detection of ground moving targets with exceptional stability and performance.

While the U 215-1C operates as a single-array radar, the U 215-4C integrates four U 215-1C radar units working in unison to provide complete perimeter coverage.

Key Features
  • High data rate and superior positioning accuracy
  • Multi-Input Multi-Output (MIMO) system architecture
  • All-weather operational capability
Applications
Ideal for security surveillance in critical areas including border protection, oil fields, prisons, and other high-security facilities.
Technical Specifications
Parameter Specification
Working Mode Phased Array + Pulse Doppler
Working Frequency C Band (5.5-5.8GHz)
Detection Range 2.5km (Pedestrians)
5km (Vehicles)
Minimum Detection Range ≤100m
Azimuth Coverage 4-panel: 360°
Elevation Coverage 9°
Distance Accuracy ≤5m
Azimuth Accuracy ≤1.0°
Target Detection Speed 0.2m/s - 30m/s
Speed Precision ≤0.2m/s
Data Rate ≤1.5s
Net Weight ≤50kg
Power Supply AC220V/160W
Interface Ethernet (UDP Protocol)
Dimensions 580mm * 580mm * 820mm
Working Temperature -40°C to +60°C
Working Environment Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof
360° Surveillance Ground Surveillance Radar with 5km Vehicle Detection and All-Weather Adaptability 0
