24GHz MMIC Technology Ground Surveillance Radar with 500m Pedestrian Detection and 1000m Vessel Detection for Perimeter Protection

1
MOQ
Please consult a sales engineer
Price
24GHz MMIC Technology Ground Surveillance Radar with 500m Pedestrian Detection and 1000m Vessel Detection for Perimeter Protection
Features Gallery Product Description Chat Now
Features
Specifications
Current Range: ≤800mA@12V DC
Temperature Range: -40ºC~+70ºC
Range Resolution: 2.5m
Velocity Accuracy: ±0.07m/s
Range Measurement: 5m~500m (Pedestrians) 5m~1000m (Vessels)
Data Rate: 85ms
Highlight:

500m Pedestrian Detection Ground Surveillance Radar

,

1000m Vessel Detection Perimeter Protection Radar

,

24GHz MMIC Technology Millimeter Wave Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U-STS1-12
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
Ground Surveillance Radar for 500m Perimeter Protection
The U-STS1-12 Millimeter Wave Radar employs advanced microwave technology and digital signal processing to deliver precise positioning of moving objects within its coverage area. This security radar outputs detailed information including relative position, movement direction, and speed, providing early warning capabilities that significantly enhance prevention and emergency response for critical facilities.
Key Features
  • 24 GHz MMIC technology for superior performance
  • Digital phased array radar utilizing DBF technology
  • Detection range: ≥500m for pedestrians/vehicles, ≥1000m for vessels
  • Observation angle ≥100° with comprehensive coverage
  • Reports target position, direction, and speed data
  • Multi-target detection with individual motion trajectory tracking
  • Simple installation and upgrade process
  • Exceptional environmental adaptability - unaffected by light, dust, rain, or snow
Applications
The U-STS1-12 is ideal for protecting critical core areas including borders, airports, oil fields, mines, and waterways. When suspicious individuals enter the protected zone, the system provides immediate monitoring and alarm triggering. With its extensive coverage and precise localization capabilities, it seamlessly integrates with camera systems for target identification, elevating overall security alert levels.
Technical Specifications
Parameter Specification
Frequency Range 24GHz~24.25GHz
Modulation Wave FMCW
Bandwidth 60MHz
Data Rate 85ms
Range Measurement 5m~500m (Pedestrians)
5m~1000m (Vessels)
Velocity Measurement -19m/s~+19m/s
Azimuth Angle Range -50°~+50°
Elevation Angle Range -7°~+7°
Range Accuracy ±1m
Velocity Accuracy ±0.07m/s
Angular Accuracy ±1°
Range Resolution 2.5m
Speed Resolution 0.07m/s
Angle Resolution 12°
Voltage Range 10V~16V DC
Current Range ≤800mA@12V DC
Temperature Range -40ºC~+70ºC
IP Grade IP67
Communication Port RJ45
Installation Height 2m~4m
Weight 980g
Dimensions (H*W*D) 190 mm*190 mm*40mm
