C Band Frequency Coastal Surveillance Radar with Phased Array + Pulse Doppler Technology for All-weather Adaptability

1
MOQ
Please consult a sales engineer
Price
C Band Frequency Coastal Surveillance Radar with Phased Array + Pulse Doppler Technology for All-weather Adaptability
Features Gallery Product Description Chat Now
Features
Specifications
Minimum Detection Range: ≤100m
Detection Range: > 3km (Boats)
Working Frequency: C Band (5.5-5.8GHz)
Elevation Coverage: 18°
Speed Precision: ≤0.2m/s
Power Supply/Consumption: AC220V/DC12V (External Battery)/65W
Highlight:

C Band Frequency Coastal Surveillance Radar

,

Phased Array + Pulse Doppler Maritime Security Radar

,

All-weather Adaptability Vessel Monitoring Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U501-1C3K
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
Perimeter Coastal Surveillance Radar with Alarm System
The U 501-1C Coastal Surveillance Radar detects movement in defined areas, tracks targets crossing into alarm zones, and raises immediate alerts for security response.
Coastal Surveillance Radar U 501-1C / C Band
The U 501-1C provides state-of-the-art protection for coastline surveillance, boat traffic management, anti-collision systems, and illegal vessel monitoring. This C-band radar system is specifically designed to detect and track water surface targets, providing immediate position and coordinate information to facilitate rapid threat response planning.
Key Features
  • High data rate and positioning accuracy
  • Multi-Input Multi-Output (MIMO) system architecture
  • All-weather operational capability
Applications
Coastline monitoring, ports, bridges, reservoirs, and other critical infrastructure protection.
Technical Specifications
Item Specification
Working mode Phased array + Pulse Doppler
Working frequency C band (5.5-5.8GHz)
Detection range > 3km (Boats)
Minimum detection range ≤100m
Azimuth coverage Single panel: 90° (Dual panel: 180°, 3-panel: 270°, 4-panel: 360°)
Elevation coverage 18°
Distance accuracy ≤10m
Azimuth Accuracy ≤1.0°
Target detection speed 0.2m/s - 30m/s
Speed precision ≤0.2m/s
Data rate ≤1.5s
Net weight ≤4kg
Power supply/Consumption AC220V/DC12V (External Battery)/65W
Interface Ethernet (UDP protocol)
Dimension 324mm x 298mm x 86mm
Working temperature -40°C ~ +60°C
Working Environment Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof
