| Parameter | Specification |
|---|---|
| Working System/Mode | Phased array system (azimuth mechanical scanning + pitch phase scanning) |
| Working Frequency | S band (2.9GHz; 5 operating frequency points) |
| Detection Range | 150m ~ 10.0km (DJI Phantom 3/4 RCS≈0.01 square meter) |
| Minimum Detection Range | ≤100m |
| Azimuth Coverage | 0° ~ 360° |
| Elevation Coverage | 0° ~ 40° |
| Distance Accuracy | ≤10m |
| Azimuth Accuracy | ≤1.0° |
| Elevation Accuracy | ≤1.0° |
| Speed Accuracy | 0.5m/s - 45m/s |
| Data Rate | 4s - 6s/Round |
| Power Consumption | ≤250W |
| Power Supply | AC220V - AC240V |
| Net Weight | ≤60kg (with PTZ) |
| Interface | RJ45, UDP protocol |
| Dimension | 782mm * 434mm * 882mm |
| Working Temperature | -40°C ~ +55°C |
| Storage Temperature | -40°C ~ +65°C |
| Working Environment | Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof |
