Vehicle Mounted Convoy Bomb Jammer with 20MHz to 6GHz Frequency 100 Watts Output Power and DDS Jamming Technology

1
MOQ
Please consult a sales engineer
価格
Vehicle Mounted Convoy Bomb Jammer with 20MHz to 6GHz Frequency 100 Watts Output Power and DDS Jamming Technology
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
色: 黒
関数: 高感度、セキュリティ警報システム、EAS ハードタグのリリース、盗難防止ハードタグリムーバー EAS デタッチャー
ロック: 3ボールロック スーパー/スタンダード、3ボールクラッチ、磁気ロック、スーパーロック、スタンダード/スーパー
アドバンテージ: 最高の品質と工場価格
重さ: 12.5kg/カートン、345g
保証: 2年、1年
ハイライト:

20MHz to 6GHz Frequency Convoy Bomb Jammer

,

100 Watts Output Power Vehicle Mounted Jammer

,

DDS Jamming Technology RF Jamming System
基本情報
起源の場所: 中国
ブランド名: UND
モデル番号: U-VIP800
お支払配送条件
受渡し時間: 5～8日
支払条件: T/T
供給の能力: 100
製品の説明
SWAT Team / VIP Protection Vehicle Mounted Radio Signal Jammer Car Remote
Product Overview
The U-VIP800 is a High Power DDS Convoy Jamming System that implements the most effective and reliable RF jamming technology, equipped with a fully-integrated broadband jamming system for superior signal disruption capabilities.
Key Features
  • Ultra broadband frequency coverage from 20MHz to 6000MHz
  • 12 modular plug-and-play design for easy maintenance and upgrades
  • American Mil-spec standard case with shockproof and drop-resistance capabilities
  • Up to 20 frequency bands with DDS technology
  • Software-controlled frequency band and output power regulation
  • Driver console operation with individual module ON/OFF control
  • Continuous simultaneous interference for common RF signals
  • High power generator for excellent low noise operational capabilities
  • Integrated backup battery system for continuous silent operation
  • Smart active cooling system for continuous operation
  • Covert antenna design for discreet installation
  • Video camera with LCD monitor for interior and exterior surveillance
Technical Advantages
  • DDS jamming technology for precise frequency setting
  • High efficient output power with extended jamming radius
  • Slow start up circuit design for stable operation
  • Comprehensive protection systems: Over Heat, Over Current, Voltage, and VSWR protection
  • Easy operation with wire control panel system monitoring
  • Integrated backup battery supports one hour of continuous operation
Applications
  • Military Convoy Operations
  • VIP Protection Details
  • RIOT Control Situations
  • S.W.A.T Team Deployments
  • EOD (Explosive Ordnance Disposal) Operations
  • Electronic Countermeasure Missions
Power Amplifier Protection Systems
  • Over Heat Protection with Thermal Protector
  • Over Current Protection
  • High Input Voltage and Low Voltage Protection
  • VSWR Protection against antenna mismatch including open and short circuit
Remote Control Capabilities
  • Wire Control Panel Operation
  • Output Power LCD Indication
  • Output Power Adjustment via LCD
  • Individual Band Output Power ON/OFF Control
  • Jamming Frequency Setting via LCD Panel
Technical Specifications
Output Band Frequency Output Power Jamming Range
Channel 120-80MHz100 Watts5-500 meters
Channel 280-200MHz100 Watts5-500 meters
Channel 3200-500MHz100 Watts5-500 meters
Channel 4500-1000MHz100 Watts5-500 meters
Channel 51000-1500MHz100 Watts5-500 meters
Channel 61500-2000MHz100 Watts5-500 meters
Channel 72000-2500MHz100 Watts5-500 meters
Channel 82500-3000MHz100 Watts5-500 meters
Channel 9870-880MHz100 Watts5-500 meters
Channel 10935-960MHz100 Watts5-500 meters
Channel 111805-1920MHz100 Watts5-500 meters
Channel 122010-2125MHz100 Watts5-500 meters
Channel 132110-2155MHz100 Watts5-500 meters
Channel 143000-4000MHz25 Watts5-300 meters
Channel 154000-5000MHz25 Watts5-300 meters
Channel 165000-6000MHz25 Watts5-300 meters
OptionalFrequency of each band can be customized. RF output power can be customized.
Additional Information
Warranty: One year from delivery date
Power Supply: 50 to 60Hz, 100 to 240V AC, With AC adapter
Packing List: Mainframe * 1, Antenna * 1, Power supply * 1, Control panel * 1
