10.0km Detection Range Air Surveillance Radar with 360° Azimuth Coverage and S Band Frequency for Drone Detection

1
MOQ
Please consult a sales engineer
preço
10.0km Detection Range Air Surveillance Radar with 360° Azimuth Coverage and S Band Frequency for Drone Detection
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Faixa Mínima de Detecção: ≤100m
Cobertura Azimutal: 0° - 360°
Precisão de velocidade: 0,5m/s - 45m/s
Consumo de energia: ≤250W
Fonte de energia: AC220V - AC240V
Dimensões: 782 mm × 434 mm × 882 mm
Destacar:

10.0km Detection Range Air Surveillance Radar

,

360° Azimuth Coverage Drone Detection Radar

,

S Band Frequency Counter-UAV Radar
Informação básica
Lugar de origem: China
Marca: UND
Número do modelo: U216SR-1S10K-3D
Condições de Pagamento e Envio
Tempo de entrega: 5-8 dias
Termos de pagamento: T/T
Habilidade da fonte: 100
Descrição de produto
Drone Detection and Tracking System
360° Anti-Drone Radar with Target Coordinates Display
U216SR-1S10K-3D / S Band
The U216SR-1S10K-3D air surveillance radar is designed for comprehensive drone detection, warning, and target indication in critical security areas including borders and airports. This advanced system provides precise target trajectory information for enhanced security operations.
Key Features
  • High Real-time Performance: Real-time target detection with immediate tracking and display capabilities
  • Exceptional Environmental Adaptability: 24/7 operational capability, adaptable to night conditions, rain, snow, haze, dust, and other challenging environments
  • Advanced DBF Technology: Digital Beam Forming technology enhances anti-interference capabilities through multi-beam transmission
  • Phased Array System: Advanced active phased array technology significantly improves radar detection effectiveness
Applications
Airport security, border protection, and surveillance of other critical areas requiring comprehensive airspace monitoring.
Technical Specifications
Parameter Specification
Working System/Mode Phased array system (azimuth mechanical scanning + pitch phase scanning)
Working Frequency S band (2.9GHz; 5 operating frequency points)
Detection Range 150m - 10.0km (DJI Phantom 3/4 RCS≈0.01 square meter)
Minimum Detection Range ≤100m
Azimuth Coverage 0° - 360°
Elevation Coverage 0° - 40°
Distance Accuracy ≤10m
Azimuth Accuracy ≤1.0°
Elevation Accuracy ≤1.0°
Speed Accuracy 0.5m/s - 45m/s
Data Rate 4s - 6s/Round
Power Consumption ≤250W
Power Supply AC220V - AC240V
Net Weight ≤60kg (with PTZ)
Interface RJ45, UDP protocol
Dimensions 782mm * 434mm * 882mm
Operating Temperature -40°C to +55°C
Storage Temperature -40°C to +65°C
Working Environment Rain-proof, dust prevention, sand-prevention, moisture-proof, mould-proof, and salt-proof
