Inicio /Productos/Sistemas anti-drones/Customized Anti Drone Systems RF Neutralization Anti UAV Defense System With 360 Degree Monitoring

Customized Anti Drone Systems RF Neutralization Anti UAV Defense System With 360 Degree Monitoring

1
MOQ
Please consult a sales engineer
Precio
Customized Anti Drone Systems RF Neutralization Anti UAV Defense System With 360 Degree Monitoring
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Nombre: Sistemas anti-drones
Capacidad de producción: 10000 piezas/año
Rango de detección: Entre 1 y 3 km.
Especificación: Azimut 360 grados; espacio aéreo completo
Origen: Porcelana
Marca: WaveSonics
Paquete de transporte: Paquete de aleación de aluminio
Resaltar:

Customized Anti Drone Systems

,

RF Neutralization Anti UAV Defense System

,

Anti UAV Defense System Customized
Información básica
Lugar de origen: Porcelana
Nombre de la marca: UND
Pago y Envío Términos
Tiempo de entrega: 5-8 días
Condiciones de pago: T/T
Capacidad de la fuente: 100
Descripción de producto
Customized 3km Detection Range Anti-drone System with 360 Degree Monitoring and RF Neutralization for UAV Defense
Auto Counter UAVs Solution
Our integrated anti-drone solution provides comprehensive drone defense protection through RF sensor passive detection, radar active surveillance detection, EO/IR tracking and location of multiple detected low-flying drones, and mitigation by RF neutralization systems.
Radar Detection Subsystem
Drone detection radar enables real-time detection and monitoring with 360°/90° coverage and fast scan rates, capable of detecting drones at distances up to 1-3km with automatic detection and tracking of multiple drones.
  • Microwave Pulse Doppler technology based (C-band & S-band)
  • Detection of wide variety of moving objects including pedestrians, land vehicles, and low-flying drones
  • 360°/90° real-time monitoring capability
  • Available for short range, medium range, and long range requirements
RF Detection Subsystem
RF detection system passively detects and identifies RF transmissions related to drones, even with low-power signals or in RF noisy conditions.
  • Detects any drone emitting RF signals (known and unidentified drones)
  • 360° detection radius up to 3 kilometer diameter
  • Simultaneous detection of multiple drones during intrusion
  • Geolocation capability for both drone and drone controller
EO Visual and Thermal Camera Tracking
Our visual and thermal camera surveillance provides target viewing capability day and night, serving as an additional layer to RF/Radar systems for imaging detected targets.
  • High sensitivity tracking capability within detection range
  • Excellent visual output for day camera and thermal imaging camera
  • Visual intrusion alarm system
RF Neutralization Subsystem
Designed to neutralize unauthorized drone flights by interfering with their control and navigation signals.
  • GNSS: 1550-1620 MHz
  • Remote Control Signal: 860-930MHz; 2400-2500MHz; 5725-5850MHz
  • Optional Frequency: 5150-5350MHz; 315MHz; 433MHz
  • Omnidirectional and directional antenna options available
  • Additional jamming bands available upon demand
  • Range: Remote Control Signal 1-3km; GNSS Signal 3-5km
Monitoring Software Center
Information processing and command center for automatic UAV detection and defense system, controlling subsystems through collection, presentation, analysis, and real-time system control.
  • Simple, intuitive display and control of one or more subsystems
  • Microsoft Windows based platform
  • User definable alert and exclusion zones
  • Automatic selection of background maps
  • Continuous record and playback facility for post-event analysis
Customized Anti Drone Systems RF Neutralization Anti UAV Defense System With 360 Degree Monitoring 0
