U226-6000XP Air Surveillance Radar with 5km Drone Detection Range 360° Omnidirectional Coverage and All-Weather Performance

1
MOQ
Please consult a sales engineer
fiyat
U226-6000XP Air Surveillance Radar with 5km Drone Detection Range 360° Omnidirectional Coverage and All-Weather Performance
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Fiyat talebi
Özellikleri
Teknik Özellikler
Sıklık: 1,2-1,8 GHz
Kapsam: Azimut: 360° / Dikey: 40°
Algılama Hızı: 1m/sn - 75m/sn
Minimum algılama mesafesi: ≤150m
Maksimum Tespit Hedefleri: 200
Güç Kaynağı: AC200-AC240V
Vurgulamak:

5km drone detection range air surveillance radar

,

360° omnidirectional coverage drone detection radar

,

All-weather performance multi-functional surveillance radar
Temel bilgiler
Menşe yeri: Çin
Marka adı: UND
Model numarası: U 226 6000XP
Ödeme & teslimat koşulları
Teslim süresi: 5-8 gün
Ödeme koşulları: T/T
Yetenek temini: 100
Ürün Açıklaması
Target FPV UAV Signal Detector - Low Altitude Air Surveillance Radar
The U226-6000XP is a highly versatile multi-purpose radar system engineered for detecting and tracking a wide range of targets including humans, vehicles, vessels, and UAVs. Designed for deployment in critical areas such as borders, perimeters, airports, coastal regions, and installations, this advanced radar system offers unparalleled performance and adaptability for diverse surveillance applications.
8km Pedestrian Detection
10km Vehicle Detection
15km Vessel Detection
5km Drone Detection
Advanced Technology Features
Equipped with a high-precision radar array, motorized rotary table, and robust power adapter, the U226-6000XP leverages Digital Beamforming (DBF) and Active Phased Array Technology to deliver real-time tracking and accurate three-dimensional coordinates of multiple targets.
Key Capabilities
  • Multi-Purpose Target Detection: Capable of detecting and tracking humans, vehicles, vessels, and UAVs for comprehensive surveillance and security applications
  • High Precision Real-Time Tracking: Advanced DBF and Active Phased Array Technology provides accurate three-dimensional tracking of multiple targets simultaneously
  • All-Weather, All-Terrain Performance: Operates effectively in harsh environmental conditions including rain, snow, fog, and dusty environments
  • 360-Degree Omnidirectional Coverage: Motorized rotary table enables seamless blind-spot-free monitoring over large areas
  • Strong Interference Resistance: Built to withstand electromagnetic interference for stable operation in complex environments
  • Compact Modular Design: Easy to deploy, integrate, and maintain with compatibility for electro-optical cameras, RF detection systems, jammers, and command platforms
  • Cost-Effective Solution: Combines reliability, exceptional performance, and affordability for diverse security needs
Technical Specifications
Model U226-6000XP
Working System 30,500
Working Mode 165
Frequency 1.2-1.8 GHz
Coverage Azimuth: 360° / Vertical: 40°
Detection Range Human: 150m-8km
Vehicle: 150m-10km
Vessel: 150m-15km
Drones: 150m-5km
Detection Speed 1m/s - 75m/s
Accuracy - Speed/Distance Speed: ≤0.5m/s
Distance: ≤10m
Accuracy - Azimuth/Vertical Azimuth: ≤0.4°
Vertical: ≤0.5°
Minimum Detection Distance ≤150m
Data Rate ≥0.5Hz (Antenna Rotation ≥30rpm)
Maximum Detection Targets 200
Target Trajectory Motion Target Trajectory
Interface RJ45
Rated Power 400W
Power Supply AC200-AC240V
Dust/Water Proof IP66
Working Temperature -40℃ to +55℃
Size 820*925*360mm
Weight Radar Panel: 38kg
PTZ: 28kg
Total System: 77kg
U226-6000XP Air Surveillance Radar with 5km Drone Detection Range 360° Omnidirectional Coverage and All-Weather Performance 0
