C-Band Air Surveillance Radar with 1.2km Detection Range and All-Weather Adaptability for Perimeter Security

1
MOQ
Please consult a sales engineer
Price
C-Band Air Surveillance Radar with 1.2km Detection Range and All-Weather Adaptability for Perimeter Security
Features Gallery Product Description Chat Now
Features
Specifications
Working Frequency: C Band (5.5-5.8GHz)
Target Detection Speed: 0.2m/s - 25m/s
Peak Output: 4W/Panel
Power Supply: AC220V/40W
Dimensions: 445mm × 300mm × 400mm
Working Temperature: -40°C To +60°C
Highlight:

1.2km Detection Range Air Surveillance Radar

,

C Band Frequency Phased Array Radar

,

All-Weather Adaptability C-Band Radar
Basic Infomation
Place of Origin: China
Brand Name: UND
Model Number: U-223R- 1C1K-5D
Payment & Shipping Terms
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 100
Product Description
C-Band 3-Dimensional Air Surveillance Radar
Advanced air surveillance radar system utilizing C-Band technology with Digital Beam Forming (DBF) capabilities for precise airspace monitoring and security applications.
Applications
Designed for critical security surveillance at airports, border areas, and other high-security locations requiring reliable airspace monitoring.
Key Features
  • High data rate with exceptional positioning accuracy
  • Multi-Input Multi-Output (MIMO) system architecture
  • All-weather operational capability
  • Digital Beam Forming (DBF) technology for flexible beam control
  • Direct amplitude and phase control of radiation units
Technical Specifications
Working Mode Phased Array + Pulse Doppler
Working Frequency C Band (5.5-5.8GHz)
Detection Range 1.2km (DJI Phantom 3/4, Mavic, RCS≈0.01 square meter)
Minimum Detection Range ≤100m
Azimuth Coverage Single panel: 90° (Dual panel: 180°, 3-panel: 270°, 4-panel: 360°)
Elevation Coverage 40°
Distance Accuracy ≤10m
Azimuth Accuracy ≤1.0°
Target Detection Speed 0.2m/s - 25m/s
Speed Precision ≤0.2m/s
Data Rate ≤1.5s
Peak Output 4W/Panel
Net Weight ≤10kg
Power Supply AC220V/40W
Interface Ethernet (UDP protocol)
Dimensions 445mm * 300mm * 400mm
Working Temperature -40°C to +60°C
Working Environment Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof; Mould-proof; Salt-proof
C-Band Air Surveillance Radar with 1.2km Detection Range and All-Weather Adaptability for Perimeter Security 0
Tag:

Low Altitude Radar

UAV Radar Systems

Drone Detection Radar System
