Anti-drone system with 5km detection range using CRPC Technology and 360° coverage for comprehensive drone defense

1
MOQ
Please consult a sales engineer
prezzo
Anti-drone system with 5km detection range using CRPC Technology and 360° coverage for comprehensive drone defense
Caratteristiche Galleria Descrizione di prodotto Richieda una citazione
Caratteristiche
Specificazioni
Copertura: 360°
Intervallo di rilevamento: 5 km (raggio)
Velocità dati: 3-7 secondi
Rilevamento simultaneo: ≥ 30 droni
Intervallo di tensione: AC 100V-240V
Consumo energetico: 15 W
Evidenziare:

5km detection range Anti-drone system

,

CRPC Technology Drone defense system

,

360° coverage Counter UAV solution
Informazioni di base
Luogo di origine: Cina
Marca: UND
Numero di modello: U-DF 5000A
Termini di pagamento e spedizione
Tempi di consegna: 5-8 giorni
Termini di pagamento: T/T
Capacità di alimentazione: 100
Descrizione di prodotto
RF Spectrum Detector Drone Management Anti-drone Systems
Product Overview
The Passive RF Sensor/Detector U-DF-5000A utilizes advanced CRPC technology for comprehensive drone detection and management. This system seamlessly integrates with existing security infrastructure and is ideal for permanent installation at critical facilities including airports, petrochemical plants, and large public venues. The system also supports mobile deployment for dynamic security operations such as law enforcement, special services, and patrol missions.
Core Capabilities
  • Extensive drone database with 200+ drone models
  • White list and black list functionality
  • Simultaneous drone and operator location tracking
  • 5km radius detection coverage
  • High accuracy with minimal false alarms
  • Real-time flight path visualization on digital maps
  • Electronic fingerprint identification for drones
Key Features
Environmentally Safe Operation
Passive detection technology ensures zero interference and no impact on surrounding environments
Highly Integrated Design
All system modules consolidated within a single protective enclosure, operational immediately upon power connection
Networked Positioning
Single station directional measurement with multi-device networking capability for enhanced positioning
Scalable Integration
Compatible with radar, optoelectronic, and jamming systems for comprehensive security solutions
Operational Flexibility
Excellent transportability, rapid deployment, and superior mobility for diverse operational requirements
Technical Specifications
Custom configurations available upon request.
Model U-5000A
Detection Technology CRPC Passive Detection
Frequency Range 30MHz - 6GHz
Key Frequency Bands 433MHz, 900MHz, 1.4GHz, 2.4GHz, 5.8GHz (Others optional)
Coverage 360°
Detection Range 5km (radius)
Detection Height 1km
Data Rate 3-7 seconds
Direction Finding Accuracy 10° (following), ≤3° (hovering)
Simultaneous Detection ≥ 30 drones
Dimensions L 410 * W 330 * H 190mm
Weight 14kg
Operating Time 7*24 hours continuous operation
Positioning Capabilities Displays frequency band, brand identification, electronic fingerprint ID, bearing, distance, coordinates, altitude, and flight tracks on electronic maps (Optional)
Power Supply 220V AC, compatible with fixed power or UPS systems
Voltage Range AC 100V-240V
Power Consumption 15W
